Cabinet & furniture panels
Profiled doors and panel components for furniture production. Assembly and finishing are separate steps.
ATC · WOODWORKING
LZ-1325A ATC CNC Router for Furniture and Cabinets
An automatic tool changing CNC router for standard-size furniture panels, cabinet components and decorative woodworking. A linear tool rack supports jobs that use different cutters for profiling, pockets and routed details.
1300 × 2500 mm · 9.0 kW air-cooled ATC
02 / APPLICATIONS & FINISHED PRODUCTS
What can you make?
Explore finished-product applications for LZ-1325A. Share your material and design for a free sample test.
Wood relief decoration
Carved surface details for decorative panels and woodworking projects.
Decorative wood panels
Routed cut-out patterns for partitions, screens and interior decoration.
Illustrative application images. Final results depend on material, tooling and configuration; printing, assembly and finishing may require separate processes.
Watch the Machine in Action
Watch LZ-1325A ATC CNC Router for Furniture and Cabinets demonstration
Demonstration of the model or configuration shown on the original product page. Accessories and operating setup are confirmed for each order.
Watch on YouTubeAn automatic tool changing CNC router for standard-size furniture panels, cabinet components and decorative woodworking. A linear tool rack supports jobs that use different cutters for profiling, pockets and routed details.
Configuration & Options
Core configuration
- 9 kW air-cooled ATC spindle
- Vacuum worktable and linear tool changer
- Delta 750W servo motor sets
- Weihong NK300 control system
- Automatic lubrication and tool touch-off sensor
Options & Order Selection
- HSD air-cooled spindle upgrade
- Tool set and magazine capacity confirmed for your production
- Vacuum pump, extraction and electrical supply specified in the quotation
Confirm the selected spindle, controller, workholding, accessories and electrical supply in the quotation.
Technical Specifications
| Model | LZ-1325A |
|---|---|
| Working area (X × Y) | 1300 × 2500 mm |
| Spindle | 9.0 kW air-cooled ATC |
| Z travel reference | 300 mm; confirm actual clearance for the tool and fixture |
| Transmission | X/Y rack drive; Z TBI ball screw |
| Controller | Weihong NK300 |
| File format | G-code |
Working area and Z travel do not specify cutting thickness. Usable clearance and machining depth depend on tooling, fixtures and the material.
Applications
- Cabinet doors and panel components
- Furniture profiles and pockets
- Decorative wooden panels and reliefs
Share the exact material, thickness, drawing and required finish for tooling and workholding evaluation.
Explore the related industry solution
Frequently Asked Questions
Does ATC mean automatic sheet loading?
No. ATC changes cutting tools. Sheet loading and unloading are separate operations; any handling equipment must be specified separately.
Can you test my material before I order?
Yes. Request a free sample test with the material specification, drawing, thickness and desired finish. Sample shipping arrangements are agreed separately.
How do I select spindle power and accessories?
Share the largest part, material, machining operations and production needs. We review the job and sample results before specifying spindle power, tooling, workholding and accessories.
What support is available?
English manuals, videos and remote training support installation and operation. Delivery timing and the scope of technical support are agreed for your order.
Installation and technical supportCompare CNC Router Equipment
View the CNC router range or discuss your material and production needs with our team.
Discuss Your CNC Routing Project
Tell us your material, thickness, part size, production needs and delivery destination.
