Stone signs & plaques
Engraved lettering and borders on suitable stone, with tooling and wet machining matched to the material.
STONE · SIGNAGE
LZ-1325S Stone CNC Router with Water Tank
A CNC routing platform with a stainless water-tank table for stone lettering, relief work and suitable signage components. Select tooling, coolant handling and spindle power around the exact stone or other material to be machined.
1300 × 2500 mm · 5.5 / 6.0 / 7.5 kW water-cooled
02 / APPLICATIONS & FINISHED PRODUCTS
What can you make?
Explore finished-product applications for LZ-1325S. Share your material and design for a free sample test.
Decorative stone reliefs
Shallow stone relief applications, evaluated for stone type, tooling, depth and workholding.
Dimensional sign letters
Shaped acrylic letters for retail and business signage. Mounting and finishing complete the sign.
Illustrative application images. Final results depend on material, tooling and configuration; printing, assembly and finishing may require separate processes.
Watch the Machine in Action
Watch LZ-1325S Stone CNC Router with Water Tank demonstration
Demonstration of the model or configuration shown on the original product page. Accessories and operating setup are confirmed for each order.
Watch on YouTubeA CNC routing platform with a stainless water-tank table for stone lettering, relief work and suitable signage components. Select tooling, coolant handling and spindle power around the exact stone or other material to be machined.
Configuration & Options
Core configuration
- Stainless water tank with T-slot workholding
- Water-cooled spindle, power selected for the order
- Leadshine stepper motors and drivers
- Xing Duo Wei controller with MDRCNCRouter
Options & Order Selection
- 5.5 / 6.0 / 7.5 kW spindle configurations
- Material-specific stone or suitable non-ferrous tooling
- Coolant circulation, sediment handling and electrical specification confirmed in the quotation
Confirm the selected spindle, controller, workholding, accessories and electrical supply in the quotation.
Technical Specifications
| Model | LZ-1325S |
|---|---|
| Working area (X × Y) | 1300 × 2500 mm |
| Spindle | 5.5 / 6.0 / 7.5 kW water-cooled |
| Z travel reference | 200 mm |
| Transmission | X/Y rack and pinion; Z 20 mm ball screw |
| Controller | Xing Duo Wei |
| Worktable | Stainless T-slot water tank |
Working area and Z travel do not specify cutting thickness. Usable clearance and machining depth depend on tooling, fixtures and the material.
Applications
- Stone lettering and decorative reliefs
- Stone signage and plaques
- Suitable aluminum engraving after tooling and sample review
Share the exact material, thickness, drawing and required finish for tooling and workholding evaluation.
Explore the related industry solution
Frequently Asked Questions
Can it machine every type of stone?
No single cutter and setup suits every stone. Send the stone type, thickness, required depth and artwork so tooling, workholding and the wet-machining process can be evaluated.
Can you test my material before I order?
Yes. Request a free sample test with the material specification, drawing, thickness and desired finish. Sample shipping arrangements are agreed separately.
How do I select spindle power and accessories?
Share the largest part, material, machining operations and production needs. We review the job and sample results before specifying spindle power, tooling, workholding and accessories.
What support is available?
English manuals, videos and remote training support installation and operation. Delivery timing and the scope of technical support are agreed for your order.
Installation and technical supportCompare CNC Router Equipment
View the CNC router range or discuss your material and production needs with our team.
Discuss Your CNC Routing Project
Tell us your material, thickness, part size, production needs and delivery destination.
