Printed display panels
Shaped event and retail displays. Printing is a separate process; printed contour work requires a suitable positioning workflow.
ROUTING · CCD · KNIFE · ROTARY
LZ-1530 Pro 4-in-1 CNC Router with Camera, Knife and Rotary Axis
A larger four-function CNC platform combining a router spindle, CCD camera, vibrating knife and side-mounted rotary axis. It supports signage and woodworking jobs that combine flat sheet work with suitable cylindrical components.
1500 × 3000 mm · 3.0–9.0 kW spindle configurations
02 / APPLICATIONS & FINISHED PRODUCTS
What can you make?
Explore finished-product applications for LZ-1530 Pro. Share your material and design for a free sample test.
Cabinet & furniture panels
Profiled doors and panel components for furniture production. Assembly and finishing are separate steps.
Rotary wood components
Decorative cylindrical wood parts using the side-mounted rotary axis and suitable fixtures.
Illustrative application images. Final results depend on material, tooling and configuration; printing, assembly and finishing may require separate processes.
Watch the Machine in Action
Watch LZ-1530 Pro 4-in-1 CNC Router with Camera, Knife and Rotary Axis demonstration
Demonstration of the model or configuration shown on the original product page. Accessories and operating setup are confirmed for each order.
Watch on YouTubeA larger four-function CNC platform combining a router spindle, CCD camera, vibrating knife and side-mounted rotary axis. It supports signage and woodworking jobs that combine flat sheet work with suitable cylindrical components.
Configuration & Options
Core configuration
- Router spindle, CCD camera, vibrating knife and side-mounted rotary axis
- Vacuum table for sheet work
- CCD recognition through reference marks
- 1500 × 3000 mm flat working area
Options & Order Selection
- Spindle power and water- or air-cooling selected for the order
- XDW or DSP controller configuration
- Stepper or servo drive configuration
- Rotary fixtures, cutters, vacuum system and extraction matched to the application
Confirm the selected spindle, controller, workholding, accessories and electrical supply in the quotation.
Technical Specifications
| Model | LZ-1530 Pro |
|---|---|
| Working area (X × Y) | 1500 × 3000 mm |
| Spindle | 3.0–9.0 kW spindle configurations |
| Z travel reference | 200 mm |
| Rotary capacity reference | Up to 300 mm diameter and 3000 mm length; confirm fixture and workpiece clearance |
| Controller options | XDW / DSP |
| Camera workflow | Reference-mark recognition |
Working area and Z travel do not specify cutting thickness. Usable clearance and machining depth depend on tooling, fixtures and the material.
Applications
- Printed signage and display contours
- Furniture and decorative sheet components
- Suitable cylindrical wood carving with rotary workholding
Share the exact material, thickness, drawing and required finish for tooling and workholding evaluation.
Explore the related industry solution
Frequently Asked Questions
Does the rotary axis share the flat working table?
The illustrated machine has a side-mounted rotary axis. Confirm the overall installation space, workpiece length, diameter and holding method separately from the flat table dimensions.
Can you test my material before I order?
Yes. Request a free sample test with the material specification, drawing, thickness and desired finish. Sample shipping arrangements are agreed separately.
How do I select spindle power and accessories?
Share the largest part, material, machining operations and production needs. We review the job and sample results before specifying spindle power, tooling, workholding and accessories.
What support is available?
English manuals, videos and remote training support installation and operation. Delivery timing and the scope of technical support are agreed for your order.
