1530 CNC Router Wood Craft and Advertising Industry

4x4 CNC Router Wood Craft and Advertising Industry PRODUCT PARAMETER NO. Model Lz-1530A 1 Working Area  1500x3000x200mm 2 Packing Size 3680x2330x1880mm 3 Working Table T-Slot Aluminum Table 4 Spindle 3KW Water cooling Spindle 5 Cooling System Water cooling 6 Control System NC Studio 7 Inverter Sunfar 8 Transmission X,Y axis rack drive,Z axis screw drive 9 Guide Rail Taiwan Square rail 10 Ball Screw TBI ball screw from Taiwan 11 Drive System Leadshine driving system and stepper motor 12 Body  Welded steel T type structure as a whole 13 Spindle Speed 24000r/min 14 Control Software Artcam/Type3,other CAD/CAM 15 Traveling Speed 10m/min 16 Working Speed 8m/min 17 Reposition Accuracy 0.03mm 18 Command Code G Code*.u00*.mmg*.plt 19 Voltage AC220V/380V,50HZ/60HZ   PRODUCT DESCRIPTION 1.Stronger Machine Frame Design Welded steel T type structure as a whole, six-legged heavy-duty body,large bearing capacity with vibration temper aging treatment ensures no deformation for long time, avoid broken knife, more stable, durable. 2.Guide Rail Imported Hiwin, Taiwan linear squareguide rail with ball bearing slide block-which ensure high weight capacity,high.precision, smooth and steady running. Adopt iported precision ball screws, tools feeded with more accuracy. 3.XYZ Transmission Way Rack gear transmission for X and Y axis,higher running speed and efficiency,saving cost. Z- axis with precision ball screw, high precision and more durable. 4.Spindle Motor and Inverter Large power 3.0kw water cooling spindle which is with stable performance, lower noise,powerful and high torque，matched with high-performance frequency inverter. 5.Y axis Transmission Mode The Y axis transmission mode for stepping two-way drive, more efficient, simplified carpentry and maintenance of the processing of the maintenance work. 6.Semi-auto Lubrication System Reduce machine parts loss Encrypted oil cap, no oil leakage, use assured 7.NC Studio More functions, more efficient operating system 8.Motor and Driver China famous 86BYGH450B stepper motor and driver for XYZ-axis, high precision, fast speed and more stable,dual motor driver Y axis with traveling speed up to more than 25000 mm/min. 9.Humanized Design Power Box More humanized design, dustproof, integrated power box.
